Perforation cut/Full cut/Kiss cut/Creasing
VICUT Vulcan series flatbed cutting machine is an ideal choice for small and medium-sized production and packaging, swing tickets, cards and label samples. Processing materials include paper, cardboard, synthetic materials, films and various labels, up to 600gsm.
Using advanced digital contour cutting technology, Vulcan series flat bed creasing and die cutting machine can immediately produce plates of any shape directly from the desktop without cutting dies. It can handle full cut, half cut, crease, perforation and drawing.
Two flatbed plotter cutter models are available, FC-500VC flatbed plotter suits for placing 2pcs SRA3 sheets while FC700VC flatbed cutting plotter allows for 2pcs B2 sheets or one B1 sheet. Users can choose suitable size reasonably according to the size of processing materials, production capacity, floor space, project budget, etc.
KEY FEATURES
Plug and play
Electricity can be used, simple installation , no additional drivers needed.
One-click repeat function
Great for cutting same jobs, just need to replace paper, press "Back to Origin", then press "Repeat", no skilled people also run it easily.
Continue cutting
If you need to process two or more sheets, when cutting second paper, users can replace first paper, save time for replacing papers.
Reverse cutting/creasing
It's necessary for professional users who always like perfect results.
Compatible OS
VICUT Vulcan series flatbed cutting machine can support both Windows & Mac.
Multiple cut and crease
For some hard/thick materials, one time cut/crease is not enough, need 2 or 3 times to get nice cutting/creasing results. The cutting and creasing can be separated operation, for better cutting/creasing performance.
Technical Parameters
The FC-700VC flat bed creasing and die cutting machine is designed for on-demand cutting, creasing, perforating and kiss cutting on a wide range of sheet materials. It is a practical choice for packaging samples, swing tags, cards, labels and short-run production where quick setup and die-free workflow matter.
Instead of waiting for expensive dies, operators can produce custom shapes directly from digital files. The built-in camera system helps detect registration marks, while the QR-code workflow supports fast job matching and repeat production.
| ITEM | FC-500VC | FC-700VC |
| Configuration | Digital servo system, Flatbed | |
| Media hold-down method | Vacuum suction | |
| Maximum cutting speed | 700 mm/s (10 to 700 mm/s ) | |
| Cutting pressure | Tool 1: Max. 5.88N (600gf) Tool 2: Max. 5.88N (600gf) | |
| Effective cutting area | 495x685mm | 790x1085mm |
| Mountable media(Y-axis direction) | 640mm | 940mm |
| Minimum character size | 5mm square | |
| Mechanical resolution | 0.005mm(5pm) | |
| Programmable resolution | HP-GL: 0.025mm | |
| Repeatability | 0.1mm | |
| Standard interfaces | USB2.0(FullSpeed) / U-Disk / Ethernet | |
| Memory | 32MB | |
| Command sets | HP-GL | |
| Number of tools | 3 tools | |
| Tool types | Cutter blade/Calibration tool/Creasing tool | |
| Operating screen | 4.3-inch touch LCD | |
| Power supply | 100 to 240 VAC, 50/60 Hz (Auto switching) | |
| Power consumption | Max.150VA(machine),Max.550W(vacuum pump) | |
| Operating environment | Temperature:10 to 35 degrees C(35 to 95 degrees F) | |
| Humidity | 35 to 75% RH(non-condensing) | |
| External dimensions | 981(Y)x977(X)x1047(H)mm | 1420(Y)x1212(X)x1050(H)mm |
| Packaging dimensions | 115x110x61cm (machine) 47x43x37cm (vacuum pump) | 525x430x61cm (machine) 47x43x37cm (vacuum pump) |
| G.W. / N.W. | 105kg/77kg (machine)23/20kg (vacuum pump) | 154kg/104kg (machine)23/20kg (vacuum pump) |
· Die-Free Workflow: Produce custom shapes directly from digital files without expensive cutting dies.
· Camera Registration System: Automatically detects registration marks for precise alignment.
· QR-Code Workflow: Supports fast job matching and repeatable production.
· Versatile Platform: Compatible with Windows and Mac, and integrates seamlessly into digital print finishing workflows.
· Flexible Job Handling: One-click repeat jobs and continue-cutting functions reduce setup time and increase productivity.
· Multiple Material Support: Cuts paper, cardboard, synthetic materials, films, and labels up to 600gsm.
Details Description
Camera system
The flatbed FC-500VC/FC-700VC uses a high-resolution camera to accurately detect registration marks (as small as 5 mm) and reg marks can be seen on both color and transparent materials. The ability to scan small reg marks saves materials and thus reduces production costs. The ability to scan four reg marks within less than 3 seconds saves production time and reduces costs even further.
User friendly touch screen
Easy toggle of vacuum suction: ON - fast/stable hold, OFF - easy replacement of next item; Easy toggle of arrow key speeds for carriage control: Fast (x10) / Slow (x1); Single key press to set origin or return to origin - guarantees accurate positioning. Re-cut button to instantly repeat last job.
Advanced contour cutting
The Vulcan flatbed efficiently handles materials loaded on a slant and also compensates for size/shape distortions. Precise and accurate cuts are assured with our proprietary four mark high-tech detection algorithm.
Network interface
A. Stable communications over long distances
B. Control one flatbed cutting plotter from multiple computers
C. Control different flatbed cutting plotters from one computer
U-Disk function
PLT-files saved on USB thumb drives (U-disk) can be used for direct output. This means that the FC-500VC/FC-700VC can be used without being connected to a computer.
QR-code system
The flatbed cutter reads QR-codes on the printed media, allowing automatic matching of print and cut files. This both speeds production and eliminates any chance of mismatched files.
SignCut Pro
Work with SignCut Pro software from Sweden, lifetime technical support and continually updating.
Tools & Accessories
Muffler
Reduce the sound level of vacuum pump. suitable for vacuum pump more than 750W. Mostly used in office which require cutter works quietly.
Vacuum pump
Powerful vacuum pump with acoustic cover, offering enough power to hold the printed sheets on the working table.
Pressure relief valve
Unique design, stabilize air pressure, ensure the steady work of suction system, prolong the service life of vacuum pump.
Double side rubber cutting Mat
The green self-healing mat is ideal for obtaining crisp cuts on thinner materials.This cutting mat can be used on both sides, greatly saving the cost of users.
Grey felt cutting mat
This cutting mat is perfect for achieving deeper creasing lines and cuts on thicker substrates. It's also very durable.
Creasing Tool
Creasing tool with ceramic ball point, creasing effect is better while protect the material, longer service life, easy to replace.
Calibration tool
Used for setting up and calibrate cutter before machine working.
Cutting blade 30 degree
Replacement 30° angle good for cutting thicker, more dense material. 5 Pack of Durable Replacement Blades. Fine sharpened tip excellent for detail work.
Cutting blade 60 degree
Replacement 60° Blade for the Vulcan faltbed cutter 5-pack of blades good for cutting most materials.
Blade holder
This precision engineered components sits in the dual tool head and holds the cutting blade of choice. The tool is adjustable manually to obtain the desired length of blade-tip. Keep an extra blade holder handy to minimize blade adjustment when working with different materials.
Application
FC-700VC is ideal for packaging prototypes, folding carton samples, presentation cards, swing tickets, labels, stickers and other sheet-based print finishing jobs. It also fits small and medium production environments that need a reliable cutter for frequent job changes and short lead times.
Process Materials: cardboard, craft paper, fibrous cardboard, eva rubber, PVC, sandblast, vinyl, sticker, magnetic sticker,PET, TPU, reflective film and thin film etc.
Application Fields: Prototype and light production, DIY paper crafts, tags, on-demand packaging and sheet card cutting system – also suitable for sheet labels.
| FC-700VC |  | Effective cutting area 790x1085mm.This digital flatbed cutter is suitable for bigger size sheets production. Four sheets of A3+ size paper can be placed on this table next to each other, and flatbed plotter cutting machine is also suitable for 2pcs B2 sheets or a single sheet of B1 size paper. This model flatbed usually most suitable for post-processing of inkjet and press printing applications. |
Working samples:
 |  |  |  |
 |  |  |  |
 |  |  |  |
 |  |  |  |
Company Service
As a professional flatbed die cutting machine supplier, Vicut believe good product quality and service always get loyal clients, CE, SGS and BV certified cutting machines, 24/7 online service, all-round technical support & solutions offered within 8 hours. Remote training, available user manual and operation video are provided.
Q1: Is FC-700VC suitable for short-run production?
Yes. FC-700VC is designed for small and medium-sized production, sample making, and on-demand jobs without the need for cutting dies.
Q2: What materials can it cut?
It can process paper, cardboard, synthetic materials, films, and labels, including media up to 600gsm.
Q3: Does it support crease and kiss cut jobs?
Yes. It handles full cut, half cut, crease, and perforation to meet most print-finishing requirements.
Q4: Is it suitable for packaging and label finishing?
Absolutely. FC-700VC is optimized for packaging prototypes, labels, cards, and other on-demand sheet-based applications.
