Vinyl Cutting Plotter

Cutting Plotter GR8000

PRODUCT PROFILE

VICUT GR8000 Series of high performance cutting plotter offers advanced solution for users from automotive aftermarket,road safety,sign,graphic and counter-top installation. It is capable of processing paint protection film(PPF),window tinting,diamond grade reflective film,sandblast resist rubber,card paper,self-adhesive vinyl, Amberlith and Rubylith,etc.


KEY FEATURES

  • Cutting Plotter GR8000

    HIGH PRECISION

    The GR8000 series is able to cut small text strings,and it is easy to tear off the scraps.

  • Cutting Plotter GR8000

    STABLE ACCURATE TRACKING REACH TO 700MM

    The combination of accurate rigid push rollers,precise material feeding rollers and quality media bracket rollers ensure long stable.

  • Cutting Plotter GR8000

    FAST SPEED

    Maximum speed reach to 800mm/s, acceleration speed 4000mm/s.

  • Cutting Plotter GR8000

    BIG CUTTNG FORCE

    Max.cutting force: 600gf / 5.8N. It is capable of processing thick materials.

  • Cutting Plotter GR8000

    STATIC ELECTRICITY FREE

    The static interference is a headache for cutter plotters.The GR8000 series cutter eliminates the static interference successfully and having been tested year-round in different weather conditions.

  • Cutting Plotter GR8000

    CUTTNG FORCE IN 8 STEPS

    Color the cutting paths differently to put different force steps,set the processing sequence with color sequence.

  • Cutting Plotter GR8000

    AUTOMATIC LEVELING

    Grating ruler is used to guarantee the cutting depth always be same.

  • Cutting Plotter GR8000

    COMPATIBLA WITH AUTOCAD,AI, FLEXSIGN, CORELDRAW

    Adapt to the latest version of popular CAD / CAM software, such as AutoCAD, Adobe Illustrator, Coreldraw and Flexisign.

  • Cutting Plotter GR8000

    NO NEED OVERCUT

    On every cutting path,the start point and end point coincide accurately,while no need any OVERCUT.

Technical Parameters

MODELGR8000-80GR8000-140GR8000-180
Max Cutting Width
(Non-contour Cutting)
690mm1290mm1630mm
Max Cutting Width
(Contour Cutting)
600mm1220mm1520mm
Max mountable media width840mm1440mm1780mm
Min mountable media width70mm
Maxcutting speed800mm/s
Maxcutting force600gf/5.8N in 8 steps
Cutting force setupAdjustable in every 1gf
DriveServo
Mechanical resolution0.0125mm
Min circle diameter0.8mm
Min. character size1×1mm
Min number size3×3mm
IOSWin10/8/7/XP
Memory buffer2MB
SoftwareWindows Driver,Sianworkpro,CADtoPlot pro
LCDEnglish
File formatHP-GL,PLT
Port in standardUSB,RS-232
Registration marks sensingRed light sensor (CCD camera is optional)
Power Input90V-240VAC,50-60H
Power consumption60W
Cutter holder/pen holder1 for each
Cutter blade diameters0.9mm,1.5mm,2.0mm
Cutter blade angles30°,45°,60°
Types of penWater based fiber-tip pen & Oil based ball pen
Method to fix materialPush rollers
Media stock roller platesIncluded
BasketFor option
Package size L-W-H1180×400×570mm1710×400×570mm2200×400×570mm
Gross/Net weight42/27kg96/62kg105/72kg



Details Description

Tools & Accessories

  • Cutting Plotter GR8000

    Fine Blade Holder

    This precision engineered components sits in the advanced carriage and holds the cutting blade of choice. The tool is manually adjustable to obtain the desired amount of “ blade out” for the job in hand.

  • Cutting Plotter GR8000

    Calibration Tool

    Used at set up and then periodically, to calibrate the cutter.

  • Cutting Plotter GR8000

    Cutting Blades

    Various blades available for different applications. Angle:45° /Φ0.9mm for Vinyl media Angle:45°/Φ1.5mm for Thick media Angle:30°/Φ1.5mm for Thicker media or smaller character Angle:60°/Φ2.0mm for reflective film Angle:45°/Φ2.0mm for PPF

Application

Various printable self-adhesive materials can be used. Such as, Photo Paper, T-shirt Transfer Paper, Photo Quality Inkjet Card, Stickers, Glossy paper, Transparent Films, etc.

GR series cutting plotter


Packing photos

Cutting Plotter GR8000
