Perforation cut/Full cut/Kiss cut/Creasing
VICUT Vulcan series flatbed cutting machine is an ideal choice for small and medium-sized production and packaging, swing tickets, cards and label samples. Processing materials include paper, cardboard, synthetic materials, films and various labels, up to 600gsm.
Using advanced digital contour cutting technology, Vulcan series flatbed cutting plotters can immediately produce plates of any shape directly from the desktop without cutting dies. It can handle full cut, half cut, crease, perforation and drawing.
Two models are available, FC-500VC and FC-700VC. Users can reasonably select the appropriate size according to the size of processing materials, production capacity, floor area, project budget, etc.
KEY FEATURES
Simple installation
Plug and play, no additional drivers needed.
One-click repeat function
Great for cutting same jobs, just need to replace paper, press "Back to Origin", then press "Repeat", no skilled people also run it easily.
Continue cutting
If you need to process two or more sheets, when cutting second paper, users can replace first paper, save time for replacing papers.
Reverse cutting/creasing
It's necessary for professional users who always like perfect results.
Compatible OS
VICUT Vulcan series flatbed cutting machine can support both Windows & Mac OS.
Multiple cut and crease
For some hard/thick materials, one time cut/crease is not enough, need 2 or 3 times to get nice cutting/creasing results. The cutting and creasing can be separated operation, for better cutting/creasing performance.
Technical Parameters
| ITEM | FC-500VC | FC-700VC |
| Configuration | Digital servo system, Flatbed | |
| Media hold-down method | Vacuum suction | |
| Maximum cutting speed | 700 mm/s (10 to 700 mm/s ) | |
| Cutting pressure | Tool 1: Max. 5.88N (600gf) Tool 2: Max. 5.88N (600gf) | |
| Effective cutting area | 495x685mm | 790x1085mm |
| Mountable media(Y-axis direction) | 640mm | 940mm |
| Minimum character size | 5mm square | |
| Mechanical resolution | 0.005mm(5pm) | |
| Programmable resolution | HP-GL: 0.025mm | |
| Repeatability | 0.1mm | |
| Standard interfaces | USB2.0(FullSpeed) / U-Disk / Ethernet | |
| Memory | 32MB | |
| Command sets | HP-GL | |
| Number of tools | 3 tools | |
| Tool types | Cutter blade/Calibration tool/Creasing tool | |
| Operating screen | 4.3-inch touch LCD | |
| Power supply | 100 to 240 VAC, 50/60 Hz (Auto switching) | |
| Power consumption | Max.150VA(machine),Max.550W(vacuum pump) | |
| Operating environment | Temperature:10 to 35 degrees C(35 to 95 degrees F) | |
| Humidity | 35 to 75% RH(non-condensing) | |
| External dimensions | 981(Y)x977(X)x1047(H)mm | 1420(Y)x1212(X)x1050(H)mm |
| Packaging dimensions | 115x110x61cm (machine) 47x43x37cm (vacuum pump) | 525x430x61cm (machine) 47x43x37cm (vacuum pump) |
| G.W. / N.W. | 105kg/77kg (machine)23/20kg (vacuum pump) | 154kg/104kg (machine)23/20kg (vacuum pump) |
Details Description
NETWORK INTERFACE
A.Stable communications over long distances
B.Control one flatbed cutting plotter from multiple computers
C.Control different flatbed cutting plotters from one computer
U-DISK
FUNCTION
PLT-files saved on USB thumb drives (U-disk)
can be used for direct output. This means that the FC-500VC/FC-70OVC
can be used without being connected to a computer.
Tools & Accessories
Muffler
Reduce the sound level of vacuum pump. suitable for vacuum pump more than 750W. Mostly used in office which require cutter works quietly.
Vacuum pump
Powerful vacuum pump with acoustic cover, offering enough power to hold the printed sheets on the working table.
Pressure relief valve
Unique design, stabilize air pressure, ensure the steady work of suction system, prolong the service life of vacuum pump.
Double side rubber cutting Mat
The green self-healing mat is ideal for obtaining crisp cuts on thinner materials.This cutting mat can be used on both sides, greatly saving the cost of users.
Grey felt cutting mat
This cutting mat is perfect for achieving deeper creasing lines and cuts on thicker substrates. It's also very durable.
Creasing Tool
Creasing tool with ceramic ball point, creasing effect is better while protect the material, longer service life, easy to replace.
Calibration tool
Used for setting up and calibrate cutter before machine working.
Blade holder
This precision engineered components sits in the dual tool head and holds the cutting blade of choice. The tool is adjustable manually to obtain the desired length of blade-tip.
Cutting blade 60 degree
Replacement 60° angle good for cutting thicker,more dense material. 5 Pack of Durable Replacement Blades. Fine sharpened tip excellent for detail work.
Cutting blade 30 degree
Replacement 30° Blade for the Vulcan SC-350 Sheet Cutter 5-pack of blades good for cutting most materials.
Application
Process Materials: cardboard, craft paper, fibrous cardboard, eva rubber, PVC, sandblast, vinyl, sticker, magnetic sticker, PET, TPU, reflective film and thin film etc.
Application Fields: Prototype and light production, DIY paper crafts, tags, on-demand packaging and sheet card cutting system – also suitable for sheet labels.
| FC-700VC |  | Effective cutting area 790x1085mm.This flatbed plotter is suitable for bigger size sheets production. Four sheets of A3+ size paper can be placed on this table next to each other, and it is also suitable for 2pcs B2 sheets or a single sheet of B1 size paper. This model flatbed usually most suitable for post-processing of inkjet and press printing applications. |
Working samples:
 |  |  |  |
 |  |  |  |
 |  |  |  |
 |  |  |  |
Packing photos
 |  |  |  |
 |  |  |  |
