ONE OF THE BEST PRICE PERFORMANCE PRINTER IN ITS CLASS
The VP500 helps streamline your labeling workflow,reduces inventory and waste. These printers are simple to use and deliver up to 2,400 labels (4x6") in 10 min. Whether you need a hundred or ten thousand labels/day, you can depend on the VP500 to deliver every time.
··High Speed Print
··Brilliant color quality Image
··Fine text, barcode and variable data
Key benefits:
··High Speed - Print 2,400 (4x 6") labels in less than 10 min.
··Brilliant color quality Image
··Large individual ink tanks
··Enhanced water-resistant inks
··Food safe & Environmentally friendly dye ink formula
Technical Parameters
| Printer | VP500 |
| Print speed | 6 and 8 ips (154 and 203 mm/second) |
| Print resolution | 1,600x 1,600 dpi and 1,600x 800 dpi |
| Print width/Length | 2” -8.5” [51 -216 mm]/Up to40” [1.016 m] |
| Comm ports | USB 2.0,10/100Base-T,GPIO |
| Inks | Five Individual 2ooml (Enhanced water resistant) dye |
| Time to first label | Less than 10 seconds |
| Print modes | Roll-to-Cut, Roll-to-Roll, Print & Hold |
| Barcode PQ | Grade B or better for ●1D barcode (Code 39) with 10 mils bar width ● 2D barcode (PDF417)with 10 miles cell size |
Electrical | Universal power supply-100-240 Vac,Peak current←4A |
Temperature | Operation:15 to 350C at RH 20-80%; Storage:-5 to 500C |
Safety/Compliant | FCC Part 15, Subpart B, Class A (US), cULus, IEC-62368-1, RCM,ccc, UKCA mark,Singapore Safety Mark |
User Interface | Embedded web server, Backlit LCD control panel in9 languages,LED for warning and readiness indication |
Acoustics | Sound pressure level← 60 dBA |
Printer Driver | WindowsTM 10 and above |
Supported Software | All major Windows based labeland graphic designapplications likeAdobe illustrator, Nicelabel, Bartender. |
Sensor type | Gap, Reflective sensor for black mark |
Media type | Roll (continuous,die-cut), fan-fold |
Media thickness | 0.1-0.3mm |
| Roll diameter | 8" (203 mm] OD with 3” (76 mm) core |
| Supported media | Glossy,matte,synthetics |
| Others | Rugged metal casing, automatic cutter, patented print & hold mechanism |
| Warranty | 1 year warranty or 5M inches,whichever earlier |
